Model:
Vertical Connection Element 1106 D-L
Mounting Type:
Vertical Base
General Information:
These products are part of the fast connection elements group and are defined as vertical connection elements. They are known in the market as Seraj, Kenet, Klemp, Clamp, Quick Connection, and Fast Connection. In the Mechanical Vertical Connection group, these clamps have a holding capacity ranging from 700 N to 5000 N. During production, the clamping arm opens at least 90° to facilitate easy loading and unloading. Models that open up to 120° are also available.
Features:
Open-arm and jaw-arm options are available.
There are four different mounting options: horizontal, vertical, front base, and front vertical.
They are made from sheet steel, similar to other connection manufacturers.
Optionally, they are produced in black.
They have a non-reflective feature, making them suitable for use in measurement laboratories.
Technical Information:
Maximum Holding Capacity (N): 745
Clamping Arm Length (mm): 73-123-173
Clamping Arm Opening Angle: 95
Movable Arm Opening Angle: 58
Available in Stock: Please contact us
Standard Material: Steel
Mounting Type: Vertical Base
Work Type: Vertical
Working Conditions: Normal
Welding Performance: Poor / Low
Mounting Performance: Excellent / High
Control Fixture Performance: Excellent / High
Part Clamping Performance: Excellent / High
Woodworking Performance: Excellent / High
Duty Cycle (Sec): 2
Product Type: Standard
Weight (kg): 0.16
